LIFT OVERVIEW

PVE 37

The PVE 37, the first pneumatic vacuum lift model, was introduced to the lift industry in 2002. The PVE 37 has paved the way for the full line of pneumatic vacuum lifts. This round, panoramic-view home lift has an external diameter of 940mm and an internal diameter of 812mm. This air-driven residential lift can safely carry two adults or 205kg up to four stops or 11m in total rise. You can also install a cabin seat, allowing passengers to sit.

The compact PVE 37 home lift is the perfect option for an existing residence as it requires little space but still provides all the desired applications of any residential lift. In both new construction and retrofit applications, many clients have chosen to feature the vacuum lift in the front entrance of their home as a work of art and conversation piece.

The PVE 37 lift operates with five individual, powerful yet economical turbines that use 5 kilowatts of electricity, making the PVE 37 environmentally friendly.

This panoramic home lift requires a 220V dedicated supply with a 32AMP D-type circuit breaker and single-phase service, similar to most washing machines or tumble dryers. In the event of a power cut, the safety system automatically switches to a slow descent.

One of the great advantages of air-driven home lift technology is its minimal maintenance: a simple annual maintenance visit and, approximately every five years or 15,000 lift operations, the main cabin seal may need to be replaced. Over time, the cost savings are significant compared with the regular service required for a traditional residential lift.

The PVE 37 offers in-line (same side) or 180° (opposite side) door openings with one door at each lift landing. Viewed externally, the door opens from left to right (top right hinged). The door opening width is 535 mm and can accommodate a passenger with a walking assistance frame.

THE FIRST VACUUM

Lift Model

  • Capacity: two person

  • Stops: two to four

  • Maximum Rise: 11 metres

  • Cabin Load Capacity: 205kg

  • Traveling Speed: 150mm per second

  • External Cylinder Diameter: 940mm

  • Internal Cabin Diameter: 812mm

  • Internal Cabin Height: 1,955mm

  • Entrance Way Opening: 535mm

  • Power Supply: 32AMP 220VAC

  • Weight of Unit: 499kg for 2 stop with 2,750mm ceilings

  • No pit excavation or machine room required

  • Self-supporting, free-standing elevator

  • In-line and 180° door openings

  • Through floor or balcony mounted

  • Aluminium and poly-carbonate cylinder structure

  • Automatic interior LED lighting and fan

  • Mechanical emergency safety brake system

  • One year limited manufacturer warranty

  • EC Certified
